ELTEC
WORK SMART AND ALWAYS SWING A BIG STICK
- Cummins engine, Interim Tier IV QSL9 – 239kW/320hp
- Amerex fire suppression system
- 24 V system, 2x150amps batteries, 110amps alternator
- 4 LED worklights, 1 inside engine compartment
- Reinforced cooling system
- D6/9R undercarriage (220 and 270 Series)
- D7/8R (310 Series)
- Air conditionning
- Kenwood KCA-RC35MR radio w/remote control
- Pnematic adjustable seat
- Oil maintenance tools
- Parts and Operator’s Manuals (plus USB key)
- Fast Speed 4,2km/hr (2,5mph)
- Medium Speed 3km/hr (1,86mph)
- Low Speed 2,2km/hr (1,4mph)
TRACTION
- High walker forestry undercarriage
- Integral guarding and ramp angles at each end
- 24 V system, 2x150amps batteries, 110amps alternator
- Sealed front idlers
- Heavy-duty tensioner
- High torque planetary track with failsafe disc brakes
- Variable displacement piston motors with integrated counterbalance valves
SWING DRIVE/TORQUE/BEARING
- The most powerful in its category
- Torque:115.2kNm (8500 lb-pi
- Heavy-duty tensioner
- High torque planetary track with failsafe disc brakes
- Continuous rotation, max 8.0tr/min
- Bearings: 1400mm (55po)
- Internal gear in grease bath
main pumps
- Hydraulic system operated by Linde VW25 Series valves, allowing a maximum flow to each function
- Main bloc located behind boom allowing an easy access, thus maintenance
cab and controls
- 3 emergency exits
- Full-length front polycarbonate window of 32mm/1,25” thickness
- Saucer Danfoss PLUS ONE control system allowing operator to personalise functions
- Right hand side full keyboards
