Shaw's LTD - VEROTOP E Wire Rope- Heavy Industry Supplier

verope

NOMINAL DIA [mm]	NOMINAL B.S[kN]	NOMINAL B.S [t]	APPROX WEIGHT [kg/m]
8	55.2	5.6	0.305
9	69.8	7.1	0.387
10	86.2	8.8	0.477
11	104.3	10.6	0.577
12	124.1	12.6	0.687
13	145.7	14.8	0.806
14	169	17.2	0.935
15	194	19.8	1.074
16	220.7	22.5	1.222
18	279.3	28.5	1.546
20	344.8	35.1	1.909

NOMINAL DIA [mm]	MINIMUM B.S [kN] 1960 Grade	MINIMUM B.S [t] 1960 Grade	MINIMUM B.S [kN] 2160 Grade	MINIMUM B.S [t] 2160 Grade	APPROX WEIGHT [kg/m]
14	187.0	19.1	192.2	19.6	0.960
16	244.3	24.9	251.0	25.6	1.254
17	275.8	28.1	283.3	28.9	1.415
18	309.2	31.5	317.7	32.4	1.587
19	344.5	35.1	353.9	36.1	1.768
20	381.7	38.1	392.2	40.0	1.959
21	420.8	42.9	432.4	44.1	2.160
22	461.9	47.1	474.5	48.4	2.371
23	504.8	51.4	518.6	52.9	2.591
24	549.7	56.0	564.7	57.5	2.821
25.4	615.7	62.7	632.5	64.5	3.160
26	645.1	65.7	662.8	67.5	3.311
27	695.7	70.9	714.7	72.8	3.571
28	748.2	76.2	768.7	78.3	3.840
30	859.9	87.5	882.4	89.9	4.408
32	977.2	99.6	1004.0	102.3	5.015

NOMINAL DIA [mm]	MINIMUM B.S [kN]	MINIMUM B.S [t]	APPROX WEIGHT [kg/m]
30	849.6	86.6	4.386
32	966.6	98.5	4.990
34	1091	111.2	5.634
36	1223	124.7	6.316

NOMINAL DIA [mm]	MINIMUM B.S [kN]	MINIMUM B.S [t]	APPROX WEIGHT [kg/m]
8	57.7	5.9	0.288
9	73	7.4	0.364
10	90.1	9.2	0.45
11	109.1	11.1	0.544
12	129.8	13.2	0.648
13	152.3	15.5	0.76
14	176.7	18	0.882
15	202.8	20.7	1.012
16	230.7	23.5	1.152
17	260.5	26.5	1.3
18	292	29.8	1.457
19	325.4	33.2	1.624
20	360.5	36.7	1.799
22	436.2	44.5	2.177
23	476.8	48.6	2.38
24	519.1	52.9	2.591
25	563.3	57.4	2.812
25.4	581.5	59.3	2.902
26	609.3	62.1	3.041
27	657	67	3.279
28	706.6	72	3.527
29	758	77.2	3.783
30	811.1	82.7	4.049
32	922.9	94	4.606
34	1042	106.2	5.2
36	1168	119	5.83
38	1301	132.6	6.496
40	1442	146.9	7.198
42	1590	162	7.935
44	1745	177.8	8.709
46	1907	194.3	9.519
